All Type of Filter Press (Plain & Zero Hold up)
TECHNICAL SPECIFICATION
| TYPE & NO. OF PLATE |
CAPACITY LT / HOUR |
FILTERING AREA M2 / LT |
CAKE HOLDING CAPACITY |
| 24” X 24 NO. |
12600 LT. |
6.500 |
126.0 LT. |
| 24” X 8 NO. |
6700 LT. |
3.430 |
148.0 LT. |
| 18” X 23 NO. |
6800 LT. |
3.400 |
65.0 LT. |
| 18” X 15 NO. |
4500 LT. |
2.270 |
44.0 LT. |
| 18” 12 NO. |
3700 LT. |
1.840 |
78.0 LT. |
| 18” X 8 NO. |
2500 LT. |
1.270 |
51.0 LT. |
| 14” X 10 NO. |
1800 LT. |
0.924 |
35.0 LT. |
| 14” X 8 NO. |
1500 LT. |
0.756 |
27.0 LT. |
| 8” X 8 NO. |
50 LT. |
0.254 |
5.7 LT. |
| 8” X 6 NO. |
400 LT. |
0.198 |
4.5 LT. |
| Size of Plate |
14” Dia X 36 mm Height |
| Nos. of Plate |
10 Nos. |
| Thick of Plate |
1.2 mm Thickness SS 316 Materials |
| Nos. of Pressure Cup |
10 Nos. SS 316 Materials |
| Nos. of Filter Screen |
11 Nos. SS 316 Materials |
| Nos. of Tai Rod for Filter Plate assembly Fitting |
5 Nos. SS 316 Materials |
| Nos. of PP Filter Pads |
11 Nos. |
| Tank’s Shell Thickness |
2.5 mm SS 316 Material |
| Tank’s Bottom Thickness |
2.5 mm SS 316 Material Dish End |
| Tank’s Top Thickness with Flange |
2.5 mm SS 316 Material Dish End |
| Tank’s Bottom Support |
04 Nos. of SS 304 Pipe Legs, Pipe 2” Dia X 2 mm Thickness. |
| Triclover end (Nozzle) |
SS 316 |
| All Gasket Material |
Silicon Food Grade |
| Surface Finish : Internal & External |
0.5 Ra Mirror Polished |
